This WRAS Approved Male x Female Standard Pattern Brass Ball Valve features a red aluminium lever handle and is suitable for general air and water duty, compressed air lines and isolaton of liquids.
Available in sizes 1/4″ to 4″, this full bore ball valve has a blowout proof stem, PTFE seats and screwed BSPP male x female end connections.
Approval
This product has been examined, tested and found, when correctly installed, to comply with the requirements of the United Kingdom Water Supply (Water Fittings) Regulations and Scottish Water Bylaws.
A valid certificate and approval number can be obtained upon request.
Details
| End Connection | BSP |
|---|---|
| Body Material | Brass |
| Seat Material | PTFE |
| Size | 1/4" (DN8), 3/8" (DN10), 1/2" (DN15), 3/4" (DN20), 1" (DN25), 1 1/4" (DN32), 1 1/2" (DN40), 2" (DN50), 2 1/2" (DN65), 3" (DN80), 4" (DN100) |
| Design | 2 Piece, Full Bore, Male x Female |
| Industry / Approvals | General / Industrial / Process, WRAS, HVAC |
| Lever | Manual Red Aluminium Handle |
| Temperature Range | -20°C to 110°C |
| Actuatable? | No – Manual Only |
